The RTR 2726A implements a new packaging scheme that boasts a smaller, lighter chassis. Enhanced capability permits up to eight recording and playback channels configurable with the right combination for a specific mission or application. An optional DC power supply enables use in ground or airborne vehicles without inverters.
The RTR 2726A has many strategic uses in the intelligence and RF testing communities. The rugged packaging and small size makes it possible to quickly and easily deploy the recorder. The incredible dynamic range of the recorder captures high resolution signal details making it an important signal analysis asset on any mission:
- Deployed in an aircraft, signals may be captured and analyzed during flight. Real-time analysis during active missions enables adjustments to be made to the mission plan to gather more appropriate intelligence.
- Adding the GPS time and position stamping option allows exact location information (longitude, latitude, and altitude) to be overlaid during mobile recording operations permitting post-mission analysis to determine exactly where a signal was captured.
- Phase coherent multichannel acquisition and external date inputs are combined with sample level time stamping to allow radar signals to be precisely recorded and perfectly reconstructed.
- Real world signals can be collected in harsh environments and then played back in lab environments for the test and development of new technology.
- Operating with the DC power option, recorders can be deployed in ground and air vehicles that may have only DC power, eliminating the weight and cost of power inverters.
The RTR 2726A features a portable, lightweight housing measuring only 16.0” W x 6.9” D x 13.0” H, weighing just less than 30 pounds. This extremely rugged workstation is reinforced with shock absorbing rubber corners and an impact-resistant protective glass for its high resolution 17" LCD monitor.
